Type1 Type 2 11kw EV Car Charger Adapter with Bluetooth, WiFi, Ethernet/4G (Optional)

Overview

Basic Info.

Model NO.	PEVC2107
Leakage Protection	Type a AC 30mA+DC 6mA
Communication Method	Bluetooth, WiFi, Ethernet/4G (Optional)
Waterproof Protection	IP55
Output Power	11kw
Output Current	16A/32A
Transport Package	Carton
Specification	325mm*260mm*500mm(W*D*H)
Trademark	Piwin
Origin	Zhuhai, Guangdong, China
HS Code	85044099

Product Description

PEVC2107 7KW 11KW 22KW EV Charger

Product Description

4.3 Inch LCD Display LCD screen can display the real-time charging status, including time, voltage, current, power and temperature.All-round protection Include voltage protection, current protection, leakage protection, temperature protection, lightning protection and other protective measures to ensure the safety.IP55, Strong and Durable Support outdoor harsh environment, waterproof and dust-proof. Rugged shell which could resist the rolling and crash of the car.High intelligence Powerful information collection, transmission and communication functions, supporting Blue tooth, Ethernet, 4G and WIFI wireless communication.Easy to install and use The installation process is simple, payment is convenient and fast, supports mobile application software or IC card swiping. Fully compatible with all EV in the market.Warranty - 24-month warranty and life-time hassle-free technical support.Product Specification

Material	ABS+PC
Installation	Wall-mounted/floor-standing
Size	Wall-mounted: 270*132*362mm(W*D*H)Floor-standing: 270*194*1500mm(WD*H)
Waterproof Protection	IP55
Input/Output	220VAC±20%/ 50Hz±5Hz
Power Factor	≥0.98
Output current	16A/32A
Output Power	11KW
Cable length	5 Meters (Custom)
Charging method	RFID card
Charging connection method	Mode C (with gun)
Communication method	Bluetooth, WIFi, Ethernet/4G (Optional)
HMI	4.3 inch LCD
Protective function	Over voltage protection, over current protection, short circuit protection,lightning protection, emergency stop protection, PE connection detection protection,LIN reverse connection detection protection, over temperature protection,anti-dumping protection, leakage protection (A type leakage MCB, )
Operating temperature	-30ºC-60ºC
Storage temperature	-40ºC-85ºC
Operating Humidity	≤95%, non-condensing

Detailed Photos

PEVC2107 is an economical AC charging station that is widely used in private parking spaces, electric vehicle manufacturers and real estate development companies; RFID reader, 4.3 inch touch screen, Ethernet/WiFi/4G Network Gateway, 1.0 rate measurement Accuracy /1.0 rate accuracy meter are all modular in design, which is convenient for users to choose and configure flexibly; It contains a type A leakage protection circuit breaker, which can reliably protect AC leakage and pulsating DC leakage; It has a PE grounding detection function, which can detect the reliability of PE wiring in real time and protect the safety of equipment use; It has a built-in temperature detection sensor, and the controller avoids accidents such as spontaneous combustion caused by over temperature during the charging process by reducing the current or disconnecting the charging.
^{_{The shell is made of ABS+PC mixed material with excellent flame-retardant performance and is suitable for various weathers.This design fully embodies the minimalist design idea, makes full use of the organic curved surface elements, and the unique circular aperture indicator is arranged around the charging plug storage seat,which has a strong overall sense, safety and reliability of industrial products, and a strong sense of technology.}}Company Profile

Zhuhai Piwin New Energy Co., Ltd. is a production-oriented enterprise integrating R&D, production, sales and service of intelligent EV charger products. Our products have more than 31 core technologies, obtained over 68 patents, and had passed the international quality system certification. To be the leading enterprice in this industry. The products have passed TUV, CE, Rosh, CB, Nemko, SAA, VDE, KC, BIS, CCC and other certification, UL certification is also under negotiation.The company has long been engaged in the R&D and production of AC and DC chargers for new energy vehicles in overseas markets, and with the capabilities of OCPP protocol docking and overseas platform deployment. The company's technology in the field of EV chargers is unique, and it has rich experience in cooperation with overseas listed companies, fortune global 500, and new energy vehicle manufacturers.Company's product concept: "Safe, Intelligent, Green, and Environmentally friendly".Our products have been sent to some important potential markets such as Europe, North America, Japan, South Korea, Southeast Asia, etc. Contributing to the early realization of carbon neutrality in the world.

FAQ

Q1: Where is your EV charger factory address?
A: Zhuhai, Guangdong, China. Welcome to visit our factory. Q2: Can you provide OEM/ODM service?
A: Yes. If you have customized requirements, please contact us. We will provide specific solutions for your requirements. Q3: Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.Q4: What is your sample policy?
A: We can supply the sample, but the customers have to pay the sample cost and the courier cost.Q5: Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery.If you can't find the exact product you need in the picture, welcome to contact us at any time, we will reply you as soon as possible.
