Portable DC charger tester ST-9980GB-DC Product Overview Saiter Portable DC charger tester ST-9980GB-DC is a device with
Basic Info.
Model NO. | ST-9980GB-DC |
Production Capacity | 100PCS/Month |
Product Description
Portable DC charger testerST-9980GB-DC
Product Overview
Saiter Portable DC charger tester ST-9980GB-DC is a device with interoperability specification testing and communication protocol conformance testing functions specified in Chinese national standards. Specially used for on-site third-party testing and product acceptance function verification of off-vehicle conductive chargers for electric vehicles, applicable to research and development by off-vehicle charger manufacturers, and on-site acceptance by third-party testing institutions! Patrol inspection can also be widely used by charging facility manufacturers to conduct early research and development debugging, factory testing, and on-site acceptance testing of off-board conductive chargers for electric vehicles, as well as by off-board charger buyers and testing units.
Product Features
1. | Interoperability testing and communication protocol conformance testing: The tester has metrological verification (optional), support for interoperability specification testing of DC charging devices for EV, communication protocol conformance testing, and BMS simulation testing functions. |
2. | Equipped with multiple communication methods such as LAN, RS232, WIFI, and built-in WIFI hotspots, remote wireless terminals can achieve remote wireless operation, making on-site operation convenient. |
3. | Using a high-precision Hall transformer with a built-in accuracy of 0.1% (optional 0.05% metering accuracy) and a range of 10-300A, and a current/voltage type test interface, multiple methods can be used for verification; High power output load gun holder, convenient and fast connection of load equipment, improving usage efficiency. |
4. | The tester realistically simulates the charging process and various faults, assists in the verification of the power supply system, and avoids issues such as incomplete testing content, inconvenient testing and use, time and power consumption during vehicle power battery charging and discharging, and shortened battery life caused by frequent charging caused by the electric vehicle real vehicle testing device. |
Technical Parameters
Product Name | Portable DC charger tester |
model | ST-9980GB-DC |
Number of gun seats | 2 (DC 1000V 250A) |
Detection object | DC charging device |
R4 equivalent resistance value | 200-11000Ω (in steps of 1Ω) |
Voltage/current sampling | ±0.5%RD(200V≤U≤1000V) / ±0.5%RD(10A≤l≤250A) |
Auxiliary source voltage/current | ±0.5%RD±30V / ±1%RD 20A |
Working power supply | 100-240V AC,50Hz ; 35W |
communication interface | LAN,RS232,WIFI |
Load power | No built-in load (external load equipment ≤ 250A) |
Dimension | L561*W455*H265 mm; |
Display Method | 10.1' touch screen |
With or without upper computer software | Yes |
Environment requirement | Working temperature: - 20 ºC~50 ºC Storage temperature: - 30 ºC~70 ºC |
Reference Standards | GB/T 18487.1-2015,GB/T 20234.1-2015,GBT 20234.3-2015,GB/T 27930-2015,GB/T34658-2017,GB/T 34657.1-2017 |
Product Overall dimension
Program Interface
Saiter Tech was established in 2015 in Shenzhen China, specialized in developing test systems for E-vehicles and EV chargers.
With a clear customer-centric approach, we aim to ensure your EV and EV chargers conformity, safety and reliability. Based on more than 5 years development, we have created mini, portable and integrated test systems - complying with GB/T, CCS(IEC/ISO/DIN/SAE) and CHAdeMO standards.
Whether mobile, laboratory racks in test E-vehicles or EV chargers, we can fulfil your demands.
Thanks to the innovative Saiter system, we can always find a solution which is precisely matching your needs.
